Why Seeing the Board Changes Everything in FPGA Bring-Up and Test

Simon Payne, CEO, XJTAG | Subscribe to LinkedIn newsletter

Read to the end to access a free tool that lets you visualise your board connections and start uncovering what’s really happening beneath the surface.

Over the past few months, we’ve been exploring a consistent theme:

The faster you can prove what’s happening on the board, the faster everything else becomes.

Two recent examples highlight this clearly, particularly when it comes to fault isolation, test coverage, and understanding complex hardware.

The Common Problem

Both teams were working with complex, high-density electronic systems:

FPGA-based designs
Dense layouts with BGAs and multiple interfaces
Systems where access to signals is limited

And both faced a familiar challenge:

When something went wrong, it was difficult to quickly identify where and why.

When Testing Happens Too Late

In one case, testing was primarily performed after full assembly.

This meant that when a failure occurred:

the system could only indicate pass/fail
root cause was unclear
troubleshooting became time-consuming

In one instance, diagnosing a single issue required around 40 hours of effort across multiple engineers.

The problem wasn’t complexity, it was visibility.

Shifting Test Earlier and Deeper

By introducing board-level testing earlier in the process, both teams were able to fundamentally change how they worked.

Instead of waiting for failures at system level, they could:

test individual PCBs before final assembly
identify faults at component level
replace or rework boards before integration

This avoided:

unnecessary disassembly
repeated debugging cycles
extended engineering effort

And in many cases, faults could be identified in minutes rather than hours.

Expanding What Can Be Tested

Another important shift was increased test coverage.

Even in systems with:

BGAs
dense routing
limited physical access

It became possible to:

access internal device pins
communicate with non-JTAG components
validate a wide range of interfaces

In one example, improved test coverage even revealed previously undetected issues in legacy test fixtures, including a short circuit that had gone unnoticed.

What This Really Means

These examples reinforce something we’ve discussed throughout this series.

The biggest gains don’t come from solving problems faster.

They come from being able to see and prove what is actually happening on the board.

When that visibility is missing:

debugging becomes guesswork
effort increases
bottlenecks appear

When it’s present:

faults are isolated quickly
confidence is established early
development and production flow more smoothly

Seeing the Connections

One of the most powerful ways to improve this visibility is simply being able to see how everything is connected.

Understanding:

which pins connect to which devices
how signals are routed
where potential issues may exist

…can dramatically reduce the time needed to understand a problem.

Closing Thought

In FPGA systems, complexity is unavoidable.

But lack of visibility doesn’t have to be.

The more clearly you can see and prove what is happening on the board, the faster you can move from uncertainty to understanding.

Introducing the Free XJTAG Layout Viewer

To get you started, XJTAG now provides a free Layout Viewer that allows engineers to visualise board connections clearly and interactively.

With the Layout Viewer, you can:

explore connections between devices and signals
quickly locate components and investigate issues

This is particularly valuable when working with:

complex FPGA systems
dense layouts
boards with limited physical access

Explore the XJTAG Free Layout Viewer

To learn more about the XJTAG Layout Viewer and how it can help visualise your board connections:

Go to XJTAG Layout Viewer

Case Studies

If you’d like to explore the full examples:

IMSAR Case Study

Narda-MITEQ Case Study
