Press Releases

14 March 2017

XJTAG DFT for Mentor Graphics PADS

Mentor Graphics PADS products now include the XJTAG DFT Assistant that provides engineers with a free, easy to use Design-For-Test (DFT) interface to check if JTAG chains are correctly connected and terminated at the schematic capture stage, long before the PCB is produced.

Featured in: eeDesignIt  |  SMT Today  |  U.S. Tech

XJTAG DFT Assistant for Mentor Graphics PADS
08 November 2016

Cadence Releases XJTAG DFT Assistant for OrCAD Capture

Cadence announced that its OrCAD® Capture has been enhanced to now include XJTAG® DFT Assistant, an easy-to-use interface that significantly increases the design for test (DFT) and debug capabilities of the schematic capture and PCB design system. The software interface enables early detection and repair of circuit board errors at the design stage, before hardware is produced.

EE Evaluation Engineering  |  U.S.Tech

XJTAG Cadence Case Study
04 October 2016

XJTAG Delivers Fast ISP Flash Configuration for ARM-Based FPGA SoCs

XJTAG announces extended capability to its high-speed In-System Programming (ISP) technology, XJFlash. For the first time, this brings the benefits of XJFlash to memory devices connected to the processor sub-system of dual ARM-Cortex-A9 based FPGAs, such as the industry’s leading Xilinx Zynq and Altera Cyclone V SoCs. Experience programming times as much as 20 times faster than existing solutions.


XJFlash high-speed Flash programming for ARM-based FPGA SoC
18 February 2016

XJTAG® Announces Free DFT Extension for Altium Designer®

XJTAG officially launches the XJTAG DFT Assistant for Altium Designer. Developed by XJTAG, the free software extension for Altium Designer significantly increases the Design for Test capabilities of the unified schematic capture and PCB design system.

The XJTAG DFT Assistant for Altium Designer provides engineers with a free, easy to use extension to check if boundary scan chains are correctly connected and terminated at the schematic capture stage, long before the PCB is produced.

EETimes  |  Electronics Magazine  |  U.S.Tech  |  Convertronic (en Español)

XJTAG DFT Assistant for Altium Designer extension
19 November 2015

XJTAG Introduces Live Signal View with Improved Multi-Core Support and Increased Productivity

XJTAG announces the release of Version 3.4 of its Development System, which introduces major improvements in the visibility into complex systems during all phases of electronic product development and manufacture.

Electronic Specifier  |  Electronics Magazine  |  Softei  |  U.S.Tech

XJTAG Waveform Viewer
04 November 2015

XJTAG Previews Major New Features to Improve Production Test and DFM&T at Productronica 2015

XJTAG will be previewing major new features of the XJTAG Development System in Hall A1, Booth 572, including Log File Viewer and Waveform Viewer.

Working in conjunction with XJTAG’s production test environment, XJRunner, Log File Viewer successfully bridges the gap between the design domain and the production test environment by allowing test engineers to capture vital fault diagnosis and convey it back to design teams, enabling effective improvements in the Design for Manufacture and Test (DFM&T) process.

XJTAG Log File Viewer
