Power and Ground Nets – Part 1

This 3-part video series shows you how to categorise power, ground, and termination voltage nets in XJDeveloper.

In this video, you will learn:

How XJDeveloper automatically suggests which nets are power, ground, or termination voltages
How to assign those nets to their relevant category
How to find relevant nets that don’t get automatically suggested
How XJDeveloper finds nets joined via ferrites or other low impedance devices

More about XJDeveloper
